제품 상세 정보:
결제 및 배송 조건:
|
| 정격전류: | 1-50A | IP 수준: | IP65 -IP68 |
|---|---|---|---|
| 연락처 자료: | 구리 | 하우징 재료: | 나일론 |
| 성별: | 남성/여성 | 모양: | 평평하게 만곡되세요 |
| Brand | Bett |
|---|---|
| Application Scope | LED industry, Marine, Geothermal, Street Lighting, Aquaculture, Laser, Lighting, Furniture, Screens |
| Types | Waterproof Plug/Waterproof Connectors/Multi-split Waterproof Plug/Nylon Waterproof Plug/Fabricated Waterproof Plug |
| Interface Type | AC/DC |
| Shape | Round/Flat Look |
| Process | Stamping/Welding/Injection Molding |
| Feature | Waterproof |
| Contact Material | Pure Phosphor Copper |
| Joint Material | PVC/PBT/PA66/PC+ABS |
| Pin Configuration | 2-12 Core |
| Pin Number | 2-12 Needle |
| Cable Length | Customizable (mm) |
| Form | Socket, Plug Stamping or Injection After Welding |
| Rated Voltage | 24V DC (AC 110V) |
| Current Rating | 1-50A |
| Breakdown Voltage | 1500V or Higher (Special Requirements Should Be Mentioned in Advance) |
| Working Temperature | -40°C to 105°C |
| Protection Grade | IP65 - IP68 (Other Requirements Available When Ordering) |
| Wire Materials | PVC, Rubber, Silicone, PE, etc. (Standard: GB RVV Sheath Cable) |
| Certification | Available per Customer Requirements: CCC, VDE, UL, ROHS, SGS, etc. |
| Appearance Color | Black, White, Transparent, etc. |
| Pin Configuration | 2 Core |
|---|---|
| Cable Cross-Section | 0.75 sq. mm (Standard) |
| Cable Length | Customizable (Standard: 20cm Male/Female Pairs) |
| Joint Material | PVC |
| Wire Type | CCC GB RVV Sheath Cable |
| Standard Length | 200mm per piece |
When ordering, please specify: pin configuration, cable cross-sectional area, color, cable length, tail stripping and tinning length (standard is 3cm stripping and 3mm tinning). Other special requirements should be submitted with your order.
Customizable any length; regular 20 cm male/female pairs available.
